Horizontal Rectanguler Autoclave / Sterilizer Manufacturers and Suppliers

Horizontal Rectanguler Autoclave / Sterilizer Manufacturers and Suppliers

PRODUCT DESCRIPTION

Multi-port operating valve, control for the entire cycle of the operation.
Permits two exhaust speeds, fat & slow.
Easy to read compound gauge for the chamber and pressure gauge for the jacket.
Smooth operation.

Self locking safety door cannot be opened while chamber is under pressure.
Gauge glass tube with automatic closing safety valve.
Heat resistant SILICONE door gasket.
Pressure switches (on electric models) economize power consumption.
Low water protection system, to protect the electric heaters.
Temperature gauge / Diigtal temp. Indicators / controllers (optional).
Vaccum breaker / dryer.
Safety valve for the Jacket / boiler.
Hydraulically test to 2.5 times the designed working pressure.
Powerful ejector for drying.
Insulated with resin bond fiber glass wool covered with M.S. / S.S. 304 sheet.

MODEL		JOEL 7	JOEL 16	JOEL 24	JOEL 30	JOEL 36	JOEL 45	JOEL 98	JOEL 128
Chamber Dim. mm / (inches)	W	450 (18)	600 (24)	600 (24)	600 (24)	900 (36)	900 (36)	1050 (42)	1200 (48)
	H	450 (18)	600 (24)	900 (36)	900 (36)	900 (36)	900 (36)	1200 (48)	1200 (48)
	D	900 (36)	1200 (48)	1200 (48)	1500 (60)	1200 (48)	1500 (60)	2100 (72)	2400 (84)
Chamber Vol.	Lit.	182	432	648	810	972	1245	2646	3456
External Dimension	W	650	800	800	800	1200	1200	1250	1400
	H	1800	1800	2000	2000	1800	1800	2000	2000
	D	1200	1400	1400	1700	1400	1700	2300	2600
